SolidWorks Flow Simulation
SOLIDWORKS® Flow Simulation is an intuitive Computational Fluid Dynamics (CFD) solution embedded within SOLIDWORKS 3D CAD that enables you to quickly and easily simulate liquid and gas flows through and around your designs to calculate product performance and capabilities.
FEATURES
| FEATURES | SOLIDWORKS Flow Simulation | HVAC Module | Electronics Cooling Module |
|---|---|---|---|
| Ease of Use | |||
| Design Data Reuse | |||
| Multi-Parameter Optimization | |||
| SOLIDWORKS Flow Simulation Capabilities | |||
| Material Database | |||
| Internal | |||
| External | |||
| 2D – 3D | |||
| Heat Conduction in Solids | |||
| Gravity | |||
| Rotation | |||
| Free Surface | |||
| Symmetric | |||
| Gases | |||
| Liquids | |||
| Steam | |||
| Boundary Layer Description | |||
| Mixing Flows | |||
| Non Newtonian Fluids | |||
| Flow Conditions | |||
| Thermal Conditions | |||
| Wall Conditions | |||
| Porous Components | |||
| Visualization | |||
| Results Customization | |||
| Communication & Reporting | |||
| Two-phase (Fluid + Particles) Flows | |||
| Noise Prediction (Steady State and Transient) | |||
| HVAC Conditions | |||
| Tracer Study | |||
| Comfort Parameters | |||
| Electronic Conditions | |||
